Aluminium Cutting Machine 14 Inch – 45°/90° Single Head
The MEPCCSH1 is a single-head aluminium and uPVC profile cutting machine built for precision miter cuts at both 45° and 90° angles. Whether you need a 90-degree cutting machine for straight cuts or a 45-degree aluminium cutter for perfect corner joints, this machine delivers both in one compact unit — making it the ideal uPVC single head cutting machine for fabrication workshops.
Equipped with an integrated pneumatic clamping system, it holds aluminium window profiles and uPVC channel profiles firmly in place, eliminating vibrations for a burr-free finish. The rapid-adjustment mechanism makes switching between angles fast, boosting throughput in high-volume uPVC cutting machine setups.
Compatible with all standard aluminium and uPVC profiles, it runs on compressed air only — no electrical motor needed for the clamping mechanism. Widely used across India as a reliable uPVC profile cutting machine and aluminium window cutting machine for doors, windows, and facade fabrication.
Key Features
View on IndiaMartApplications
Where This Machine Excels
Aluminium Window Fabrication
- Sliding window frames
- Casement window profiles
- Door frame sections
- Curtain wall mullions
uPVC Profile Processing
- uPVC window sashes
- uPVC door frames
- Tilt & turn profiles
- Multi-chamber profiles
Industrial Applications
- Architectural aluminium sections
- Solar panel frames
- Partition system profiles
- Facade cladding channels
Key Industries Served
- Construction & real estate
- Interior design firms
- Glass & glazing companies
- Aluminium fabrication workshops
Compare
Variants Available
| Blade Size | 14" | 16" | 18" |
|---|---|---|---|
| Power | 3 HP | 5 HP | 5 HP |
| Warranty | 6 Months | 6 Months | 6 Months |
| Motor | Rotomotive/CG | Rotomotive/CG | Rotomotive/CG |
Specifications
Technical Specifications
Reviews
What Our Customers Say
"We do commercial glazing work in Bangalore and needed a reliable cutting machine. Went with Mechnovate 45/90 degree cutter after comparing 3-4 brands. Cutting accuracy is good, blade lasts long. One thing I will say — the user manual could be better, we had to call their support to understand the fence adjustment. But the machine itself is solid. Using it daily for 6 months now."
"Got the cutting machine delivered in just 1 day since we are in Surat and their factory is Ahmedabad. Machine works well, cuts are clean on both angles. We mainly use it for aluminium sections. The clamp could be slightly better designed for very thin profiles — sometimes needs extra care. But for the price point, no complaints. Their engineer did a good setup demo."
"Bought complete setup from Mechnovate — cutting machine, punching machine, copy router. They gave us package pricing which was reasonable. All 3 machines came together and their team installed everything in 2 days. Been running for about 3 months now. Cutting machine is excellent. Punching machine is good. Copy router takes a bit of skill to operate but our guys got hang of it after a week. Would recommend for anyone starting fresh."
"We have the 45/90 cutting machine. Being in Ahmedabad we went to their factory and saw the machine running before buying. Cutting is precise, blade lasts a long time. One small thing — the measuring scale on the fence is in mm only, would have been nice to have inches also for some of our clients who give measurements in inches. Small thing but worth mentioning. Machine overall is excellent quality."
"Cutting machine reached Coimbatore in 4 days. Machine is good, cuts are clean on both 45 and 90 degree. We work with aluminium and uPVC both — works well on both materials with different blades. The motor is powerful enough for thick aluminium sections. One feedback — the dust collection could be better designed, we end up with aluminium chips around the machine. But cutting quality itself is top notch."
"We manufacture custom windows in Bhopal and rely on the Mechnovate cutting machine for all our profile cutting. Accuracy has been consistent — mitre joints fit well without requiring extra filing. The machine handles the daily workload of 50-60 cuts without any performance drop. We also bought TCT blades from them which are genuine quality. Happy with the overall experience. Would recommend to fabricators in MP region."
FAQ
Frequently Asked Questions
Common questions about the Single Head Cutting Machine for Aluminium and UPVC.
Pricing Info
Single Head Cutting Machine for Aluminium and UPVC Price & Availability
Place Your Order
Buy Single Head Cutting Machine for Aluminium and UPVC
Submit your order enquiry — our team calls you within 2 hours to confirm
Single Head Cutting Machine for Aluminium and UPVC
Model: MEPCCSH1
Explore More
Related Cutting Machines
2 Station Pneumatic Aluminium Punching Machine
Model: MEPPPST2
View Details →
1 Station Pneumatic Aluminium Punching Machine
Model: MEPPPST1
View Details →
Pneumatic Copy Router Machine for Aluminium and UPVC
Model: MEPCR Series
View Details →
Manual Copy Router Machine for Aluminium and UPVC
Model: MEMCR Series
View Details →About Single Head Cutting Machine for Aluminium and UPVC
The Mechnovate 45/90 Degree Cutting Machine (Model: MEPCCSH1) is our most popular aluminium and uPVC profile cutting solution. Designed for rapid switching between 45-degree mitre cuts and 90-degree straight cuts, this machine is the backbone of thousands of window fabrication workshops across India. It delivers clean, burr-free cuts on aluminium extrusions up to 3mm wall thickness and all standard uPVC multi-chamber profiles.
The MEPCCSH1 combines a rigid cast-iron body with a pneumatic saw feed mechanism to deliver consistent cut quality shift after shift. The angle changeover system uses precision-machined stops — the operator releases a locking lever, swings the saw assembly to the desired angle, and locks it in place in under 5 seconds.
The pneumatic clamping system uses a wide-jaw design that contacts the profile over a large surface area, preventing marking on soft aluminium and delicate uPVC profiles.
Key Features — Single Head Cutting Machine for Aluminium and UPVC
Rapid Angle Changeover
Switch between 45 and 90 degrees in under 5 seconds using the quick-lock lever mechanism. Precision-machined angle stops ensure repeatable accuracy without the need for angle measurement.
Cast-Iron Construction
The machine body is cast from high-grade grey iron with machined mounting surfaces. Cast iron absorbs vibration better than fabricated steel, delivering smoother cuts and longer blade life.
Wide-Jaw Clamping
Pneumatic clamps with 80mm-wide jaws distribute clamping force evenly across the profile. This prevents profile distortion and eliminates the clamping marks that narrow-jaw systems leave on soft aluminium.
Integrated Chip Collection
A built-in chip tray with a removable drawer captures 90% of cutting chips at the source. The work area stays clean and safe without a separate chip extraction system.
How It Works — Working Principle
The operator positions the profile against the rear fence and side stop, selects the cutting angle (45 or 90 degrees), and activates the pneumatic clamp. The saw assembly descends through the profile in a controlled arc powered by a pneumatic cylinder.
The cutting speed is adjustable via a flow control valve, allowing the operator to slow the feed for thick aluminium sections or speed it up for thin uPVC profiles. After the cut, the saw retracts automatically and the clamp releases.
Ideal For
- ✓Entry-level window fabrication workshops
- ✓Small to mid-sized fabricators doing 5-30 windows per day
- ✓Workshops needing a versatile dual-angle cutting machine
- ✓Fabricators working with Domal, Jindal, and European aluminium systems
- ✓Mobile fabrication setups where space and weight matter
Maintenance Tips — MEPCCSH1
- ●Apply a drop of pneumatic oil to the saw arm pivot bearing daily. A dry bearing causes jerky saw movement and rough cut surfaces.
- ●Check the angle stop faces for aluminium chip deposits weekly. Even a thin layer of chips shifts the cutting angle by 0.5-1 degree.
- ●Adjust the pneumatic flow control valve seasonally — colder temperatures increase air viscosity, requiring a slightly more open setting for the same cutting speed.
- ●Inspect the rear fence for straightness monthly using a precision straightedge. A bent fence causes the profile to sit at a slight angle, producing cuts that are off-square.
Why Choose Mechnovate Single Head Cutting Machine for Aluminium and UPVC?
- ✓Precision-engineered cutting machine for aluminium and uPVC window profiles — handles all standard Indian profile systems including Domal, Jindalinium, and European systems.
- ✓Manufactured in Ahmedabad, Gujarat with rigorous quality standards. Every machine is tested before dispatch with actual aluminium and uPVC profiles to ensure cut quality and dimensional accuracy.
- ✓Factory-direct pricing with no distributor markup. GST invoice provided. Same price for buyers across India — whether in Delhi, Mumbai, Bangalore, Chennai, or any other city.
- ✓24/7 after-sales support via WhatsApp and phone. Spare parts stocked in Ahmedabad and dispatched same-day. On-site warranty repairs by Mechnovate technicians.
- ✓6-month comprehensive warranty covering parts and labour. On-site installation and operator training available on request.
Applications of Single Head Cutting Machine for Aluminium and UPVC
🏢 Aluminium Window Fabrication
- ●Sliding window frames
- ●Casement window profiles
- ●Door frame sections
- ●Curtain wall mullions
🏭 uPVC Profile Processing
- ●uPVC window sashes
- ●uPVC door frames
- ●Tilt & turn profiles
- ●Multi-chamber profiles
🔧 Industrial Applications
- ●Architectural aluminium sections
- ●Solar panel frames
- ●Partition system profiles
- ●Facade cladding channels
🎯 Key Industries Served
- ●Construction & real estate
- ●Interior design firms
- ●Glass & glazing companies
- ●Aluminium fabrication workshops
Technical Specifications — MEPCCSH1
| Parameter | Value |
|---|---|
| Model | MEPCCSH1 |
| Blade Size | 350 mm (14 inch) TCT |
| Clamping Type | Pneumatic |
| Cutting Angles | 45° and 90° |
| Machine Weight | 150 kg |
| Power Required | Single-phase or 3-phase, plus compressed air (6–8 bar) |
| Profile Thickness | Up to 3 mm |
| Operating Pressure | 6–8 bar |
| Profile Compatibility | Aluminium & uPVC |
| Machine Size (L × W × H) | 800 × 800 × 1100 mm |
Frequently Asked Questions — Single Head Cutting Machine for Aluminium and UPVC
What makes this different from other 45/90 cutting machines?
The MEPCCSH1 uses a cast-iron body instead of fabricated steel, which absorbs vibration better for smoother cuts. The wide-jaw pneumatic clamping prevents the profile marking that is common with cheaper narrow-jaw machines. Every machine is test-cut with actual aluminium and uPVC profiles before shipping.
What blade size does this machine use?
The machine uses a 350mm TCT saw blade with a 30mm arbor bore. We supply premium Italian-made TCT blades optimized for aluminium cutting, and replacement blades are available with same-day dispatch from Ahmedabad.
Can I cut profiles at angles other than 45 and 90 degrees?
The standard machine has preset stops at 45 and 90 degrees. Custom angle stops can be installed for special applications — contact our engineering team with your requirements.
Buying Guide — Cutting Machine
When choosing a cutting machine for your aluminium and uPVC window fabrication workshop, consider your daily production volume, the profile systems you work with, and the specific operations you need to perform. Mechnovate manufactures machines for workshops of all sizes — from small fabricators doing 5–10 windows per day to large production facilities processing 100+ windows daily.
Every Single Head Cutting Machine for Aluminium and UPVC shipped from our Ahmedabad factory includes a 6-month comprehensive warranty covering parts and labour. On-site installation by a trained Mechnovate technician and operator training are available on request. Spare parts and consumables are stocked in Ahmedabad and dispatched same-day to any location in India.
Need help choosing the right cutting machine?
Factory price: ₹1,55,000 + GST — direct from manufacturer in Ahmedabad, no dealer markup.
Call +91-9265699061 or email sales@mechnovate.co.in for a custom quote based on your workshop requirements.
WhatsApp Us for Price & DetailsAluminium Cutting Machine Price in India
The MEPCCSH1 14-inch aluminium cutting machine costs from ₹1,55,000 + GST, ex-factory Ahmedabad. It is a factory-direct price with a GST invoice, the same for buyers anywhere in India. The final price depends on the power configuration (single-phase or 3-phase), any extra blades, and delivery and installation to your city.
Looking for a low-price option? Portable saws cost less, but for daily window fabrication an industrial cutting machine for aluminium pays back through accurate, repeatable cuts and less rework. Call +91-9265699061 for today's price.
14 Inch Aluminium Cutting Machine Specifications
A 14-inch (350 mm) blade gives more cutting capacity than 12-inch saws, so larger aluminium window and door profiles can be cut in one pass.
| Model | MEPCCSH1 |
|---|---|
| Blade | 14 inch (350 mm) TCT |
| Cutting angles | 45° and 90° |
| Profile thickness | Up to 3 mm |
| Clamping | Pneumatic |
| Power | Single-phase or 3-phase, plus compressed air (6–8 bar) |
| Machine size | 800 × 800 × 1100 mm |
| Weight | 150 kg |
| Materials | Aluminium and uPVC profiles |
| Warranty | 6 months |
| Price | From ₹1,55,000 + GST |
Industrial vs Small Aluminium Cutting Machines
Small portable mitre saws (from brands such as Bosch, DeWalt and Makita) are popular for cutting aluminium on site. Here is how they compare with an industrial machine built for window fabrication.
| Factor | Small portable mitre saw | MEPCCSH1 industrial (14 inch) |
|---|---|---|
| Built for | Occasional or on-site cutting | Daily aluminium window production |
| Clamping | Hand-held or manual clamp | Pneumatic clamping |
| Angles | Set by hand for each cut | Fixed 45° and 90° stops |
| Base | Light and portable | 150 kg, vibration-free |
| Price | Lower | From ₹1,55,000 + GST |
| Support | Retail warranty | Factory installation, training, 6-month warranty |
Brand names belong to their owners. Mechnovate is not affiliated with them.
14 Inch Aluminium Cutter Machine — Blade and Cutting Specification
The MEPCCSH1 is also known as an aluminium profile cutter, aluminium cutting machine 14 inch or 14 inch aluminium cutter machine. It is a single head cutter for aluminium window and door profiles and uPVC profiles, set to 45° or 90°.
- ✓Blade: 14-inch (350 mm) carbide-tipped (TCT) circular saw blade with a 30 mm arbor bore, made for clean cuts in aluminium and uPVC.
- ✓Cutting angles: Fixed stops at 45° (mitre) and 90° (straight), changed over with a locking lever in about five seconds.
- ✓Profile thickness: Cuts aluminium and uPVC profiles up to 3 mm wall thickness.
- ✓Clamping: Wide-jaw pneumatic clamps hold the profile without marking it, so cuts stay square and burr-free.
- ✓Spare blades: Replacement blades dispatch from Ahmedabad.
How to Choose the Best Cutting Machine for Aluminium
- ✓Blade size: Choose a blade large enough for your biggest profile. A 14-inch blade covers standard aluminium window and door sections.
- ✓Clamping: Pneumatic clamping holds the profile still, which gives square, burr-free cuts every time.
- ✓Angle accuracy: Fixed 45° and 90° stops keep mitre joints tight without re-measuring.
- ✓Build: A heavy base absorbs vibration for cleaner cuts over long shifts.
- ✓After-sales support: Look for installation, operator training, spare blades and a warranty from the manufacturer.
The cutting machine is the first of the core aluminium window machines. See also the copy router machine, aluminium punching machine and all aluminium cutting machines.
Aluminium Cutting Machine — Buyer FAQs
What is the aluminium cutting machine price in India?
The Mechnovate MEPCCSH1 14-inch aluminium cutting machine costs from ₹1,55,000 + GST, ex-factory Ahmedabad. It is a factory-direct price with a GST invoice, the same for buyers anywhere in India. Call +91-9265699061 for a quotation for your configuration.
Is the MEPCCSH1 a 14 inch aluminium cutting machine?
Yes. The MEPCCSH1 uses a 14-inch (350 mm) TCT circular blade and cuts aluminium and uPVC profiles at 45° and 90°, with pneumatic clamping.
Do you make a 12 inch aluminium cutting machine?
Mechnovate makes the 14-inch MEPCCSH1. A 14-inch blade gives more cutting capacity than a 12-inch saw, so it handles the window profiles a 12-inch machine cuts as well as larger sections.
Is there a small or low-price aluminium cutting machine?
Small portable mitre saws cost less and suit occasional or on-site cutting. For daily aluminium window fabrication, an industrial machine with a heavy base and pneumatic clamping gives more accurate, repeatable cuts and less rework. The MEPCCSH1 has a compact 800 × 800 mm footprint.
Can I use a Bosch mitre saw to cut aluminium windows?
Portable mitre saws from brands such as Bosch can cut aluminium with a suitable blade and are fine for occasional work. For production window fabrication, a dedicated aluminium cutting machine with pneumatic clamping and fixed 45°/90° stops is faster and more consistent. Mechnovate is not affiliated with Bosch.
What is the best cutting machine for aluminium windows?
For most aluminium and uPVC window workshops, a 14-inch 45°/90° cutting machine with pneumatic clamping, such as the MEPCCSH1, is the right choice. Workshops cutting large repeated batches can consider a double head cutting machine, which Mechnovate supplies to order.
Is the MEPCCSH1 a single head cutting machine for 45 90 degree cuts?
Yes. It is a single head cutting machine with fixed stops at 45° and 90°. Use 45° for mitre corners and 90° for straight cuts on transoms and mullions. One saw head cuts one end at a time; for cutting both ends in one cycle, see our double head machine, supplied to order.
Can it cut Domal and other aluminium section profiles?
Yes. It cuts aluminium window and door profiles and sections up to 3 mm wall thickness, whichever profile system you use, including Domal-series sections. Fit the TCT blade for aluminium, or a uPVC-grade blade for uPVC.
Is it an aluminium window cutting machine and a uPVC cutting machine?
Yes. The same machine cuts aluminium window and door profiles, aluminium sections and uPVC profiles, so a workshop that fabricates both needs one cutting station.
