Choosing the Right Pneumatic Copy Router for Your Indian Window Workshop

A copy router is the machine that prepares aluminium and uPVC profiles for hardware installation. Every lock pocket, handle recess, drainage channel, and espagnolette slot on a finished window or door frame was routed using a template-guided cutter. Without a router, fabricators resort to hand filing — a slow, inconsistent process that introduces variation into cuts that hardware manufacturers designed to be standardised. The choice between a manual and pneumatic model, the motor you specify, and the compressor setup you pair with it all directly determine output capacity, operator fatigue, and the pocket quality your hardware fittings require.

What a Copy Router Does and Why Template Accuracy Matters

The machine uses a follower pin that traces a steel or aluminium template while a router bit removes material from the profile below. The template fixes the pocket geometry — depth, length, and width — required by the specific hardware fitting. In Indian fabrication shops, the four hardware brands that set the template standards are Giesse, Fuhr, Roto, and Siegenia.

Standard template lengths for these brands range from 200 mm to 600 mm for main lock pockets, with smaller inserts (80–120 mm) for handle recesses and drainage channel cut-outs. When selecting a machine, confirm the template holder accepts the follower pin diameter your chosen hardware brand requires — typically 8 mm or 10 mm. Mismatched templates produce off-centre pockets, causing multipoint locks to bind or fail to engage the striker plate correctly.

Pneumatic vs Manual: When to Make the Switch

A Manual Copy Router Machine, starting at ₹35,000, uses a lever and mechanical clamping system. The operator positions the profile, clamps it manually, routes the pocket, and releases. For a shop producing fewer than 15 frames per day, this workflow is manageable and the lower cost makes it practical.

At 15 frames or more, manual clamping creates repetitive strain on the operator's wrist and forearm, and clamp positioning becomes inconsistent as fatigue builds — leading to hardware fitting errors downstream. A Pneumatic Copy Router Machine, starting at ₹55,000, replaces mechanical clamping with an air-actuated clamp triggered by a foot pedal. The operator's hands remain on the profile for positioning; the pedal engages the clamp and lowers the router in one motion. This reduces per-pocket cycle time by 30–40% and keeps clamp force consistent across every pocket throughout the shift.

If your workshop targets 15 or more windows per day, or operates two shifts, the pneumatic model recovers its price premium through reduced rework and faster throughput within a few months of purchase. For a detailed side-by-side breakdown of both configurations, read the Manual vs pneumatic copy router comparison.

Motor Options for Indian Workshop Conditions

Three motors are commonly fitted to copy routers sold in India:

• Bosch GOF130 (1,300W): Best torque-to-reliability balance in this category. Handles 20 mm depth cuts in aluminium without speed drop under load. Variable speed dial lets you reduce RPM for deeper espagnolette cuts. Recommended for fabricators working with commercial-grade aluminium from Hindalco or profiles with wall thickness above 1.8 mm.
• Dong Cheng 1,860W: Higher rated wattage, capable on both uPVC and aluminium. Confirm your supplier has local service for brush replacement — motor brushes on high-cycle routers need inspection every 300–400 operating hours.
• Dong Cheng 900W: Adequate for uPVC and light aluminium with wall thickness under 1.4 mm. Not recommended for full-day aluminium routing at volume as the motor runs hot and brush wear accelerates.
• Stanley 1,200W: Mid-range motor suited to standard aluminium profiles across Domal, Jindalinium, Dumal, and Alumil section ranges at moderate production volumes.

For mixed aluminium and uPVC production at 20 or more frames per day, specify the Bosch GOF130 or Dong Cheng 1,860W. For uPVC-only or part-time aluminium work, the Stanley 1,200W is a practical fit.

Compressor Requirements: Setting Up the Air Supply Correctly

The pneumatic clamping circuit requires sustained pressure and consistent volume. The minimum specification is a 2 HP compressor with a 100-litre tank delivering 6–8 bar working pressure. A smaller tank starves the clamp between pocket cycles, causing pressure drop and inconsistent clamping force. If your workshop also uses spray lubrication on the cutter — which extends cutter life on aluminium by 40–60% — step up to a 3 HP compressor to cover both the clamp circuit and the mist circuit simultaneously.

Before connecting your machine, complete these five setup steps:

1. Confirm the compressor delivers at least 200 litres per minute free air delivery (FAD) at 7 bar.
2. Install a moisture trap and regulator on the airline before the machine — water inside the clamp cylinder corrodes the bore.
3. Set the regulator to 6 bar for the clamp circuit; exceeding 8 bar risks deforming thin-wall profiles.
4. Use 10 mm bore air hose for runs longer than 5 metres to prevent pressure drop over distance.
5. If sharing the compressor with a pneumatic punching machine, add the FAD ratings of both machines — two machines on a single 2 HP unit will cause pressure drop under simultaneous use.

Cutter Life and Planned Maintenance

Tungsten carbide spiral cutters last 500–1,000 pockets on aluminium before requiring sharpening, depending on alloy grade and whether lubrication is used. On uPVC, the same cutter runs 2,000–3,000 pockets before sharpening because the softer material generates far less heat at the cutting edge. The first sign of a dull cutter is a rough or fibrous inside edge on the finished pocket. The second sign is audible — the motor sounds heavier and slows slightly under cut.

Keep a spare set of cutters in the workshop. Swapping a dull cutter mid-shift takes two minutes and prevents ragged pockets that complicate hardware fitting. Tungsten carbide cutters can be sharpened 3–4 times before retirement, so send them for re-sharpening rather than discarding. For a complete pre-purchase checklist, read the Copy router buying guide.

FAQ

What compressor size do I need for a pneumatic copy router?

A 2 HP compressor with a 100-litre tank operating at 6–8 bar is the minimum for a single machine. This covers the clamp circuit in continuous operation. If you plan to run spray lubrication on the cutter simultaneously, upgrade to a 3 HP unit. If two machines will share one compressor, add the FAD ratings of both machines and confirm the compressor exceeds that combined figure — otherwise pressure drops between cycles will affect clamp consistency.

Which motor is better for a high-volume aluminium workshop — Bosch GOF130 or Dong Cheng 1,860W?

Both handle aluminium fabrication at production volume. The Bosch GOF130 has a stronger Indian service network and a variable speed control that helps on deeper espagnolette cuts. The Dong Cheng 1,860W offers a higher rated wattage at a lower price point. Choose the Bosch if local Bosch service is available in your city; choose Dong Cheng if your machine supplier can source motor brushes and service parts locally, since brush replacement at 300–400 hours is predictable maintenance.

Can one copy router handle templates for multiple hardware brands like Giesse, Roto, and Fuhr?

Yes, provided the template holder uses a standard follower pin diameter — 8 mm or 10 mm — that matches your template set. Most Indian copy routers accept interchangeable templates. You will need a separate template for each hardware brand and each pocket type: main lock pocket, handle recess, and drainage channel are the three most common. Confirm the follower pin diameter with your hardware supplier before ordering a new template set.

How do I know when my router cutter needs replacement or sharpening?

The most reliable indicator is a rough or fibrous edge inside the finished pocket. On aluminium, this appears after 500–1,000 pockets without lubrication. On uPVC, the same cutter runs 2,000–3,000 pockets. You will also notice the motor laboring — it sounds heavier or slows under cut. At that point, swap to the spare cutter and send the dull one for re-sharpening. A sharpened cutter typically restores full pocket edge quality and can be reused 3–4 times before the carbide geometry degrades beyond recovery.
